How to maintenance hammer mill crusher

Hammer mill crusher is a kind of hard material crushing machine with high crushing ratio. Such as stone size 50mm, it could be crushed into 5mm fine powder.Due to small machine size, low cost, more function, easy operation reasons, more and more people use this hammer crusher mill to make fine powder instead of fine powder grinding mill machine. To prolong hammer mill crusher lifetime, it is very importatant to use and maintenace it properly.

Here is 3 steps to prevention of hammer crusher accident occurred in the following measures are:

1. Properly mount the bearing and shaft parts

The bearing is a part that supports the rotor shaft and rotates it freely. When the bearings and shaft parts are not installed correctly, the rotor shaft will produce vibration, which in turn will greatly reduce the bearing life. A pair of installed correctly, using a reasonable bearing can be used for two years or longer. And when the installation is not correct, the use of unreasonable, it will greatly shorten the bearing life, can only use 3 months or even shorter time (some less than 1 month on the damaged). Severe vibration will damage the journal of the rotor shaft, making it round, deformed.

2. Correctly allocate theweight of each hammer

In the hammer to repair, arrangement, should ensure that the total weight of each hammer no more than ±1kg, the two hammers between the three hammer should be consistent, the maximum deviation of not more than 250g, more than the provisions of the hammer Should be polished.

3. Select the appropriate grate and arrangement

In the use of the grate and the arrangement design, you can use the following two forms shown. At the same time in the grate installation arrangement on the mix, that is, a triangular grate and a diamond grate staggered arrangement. This can give full play to the triangular grate large angle radioactive, easy to pass the advantages of materials, but also play a diamond-shaped grate is durable, grate gap is not easy to wear the advantages of large.

People Also Frequently Asked For- FAQ

What is hammer mill crusher?

A hammer mill, also known as a pulverizer, is designed to mill, grind and crush material. These mills have been in use for much of human history and function by using hammer blows at high speed to grind material. The material is shattered and disintegrated by the internal hammer.

How does a hammer mill crusher work?

The hammers are free to swing on the ends of the cross, or fixed to the central rotor. The rotor is spun at a high speed inside the drum while material is fed into a feed hopper. The material is impacted by the hammer bars and is thereby shredded and expelled through screens in the drum of a selected size.

Is hammer crusher same as impact crusher?

Crushing principle:The primary difference between stone hammer crushers and impact crushers is their crushing principle. Hammer crushers use a single hammer to strike and break the material, while impact crushers use a combination of hammers and a crushing plate to strike and shatter the material.
