YK Vibrating Screen

YK Vibrating Screen

YK Series circular vibrating screen can be used to separate minerals into various sizes for further processing in stone crushing plant. Baichy can design and supply all ranges of vibrating screens according to the capacity and requirement.

  • 3-150mmFeed Size
  • 5.5-55Motor Power
  • 30–850 t/hProcessing capacity
  • 60S Quick response
  • 30 min Technical reply
  • 24h design proposal
  • Email:hnbc@baichy.com

What is YK series vibrating screen?

YK Vibrating screens are used to separate materials of different particle sizes for further processing. It uses the inner eccentric shaft as excitation force to make screen machine a circular motion track of up, front, down and back, so that the screened materials can evenly slide through the screen to complete screening work. It could be made into one deck, two decks, three decks and four decks to get different size material. The vibrating screen is used for screening sand and gravel in quarries, and can also be used for product classification in coal preparation, mineral processing, building materials, electric power and chemical industries.
triple deck vibrating screen
vibrating screens mining

vibrating screen machine price

How to choose vibrating screen?

1. When selecting a vibrating screen, the shape, moisture, clay content, etc. of the screened material should be considered. Appropriate materials can improve the production efficiency of the vibrating screen.

2. Consider the screen area, movement mode, vibration frequency and other factors of the vibrating screen. For example, when the moving sieve sieves particles, the particles can vibrate on the sieve surface in a direction close to the vertical sieve hole. The vibration frequency is high and the sieving effect is better.

3. The vibrating screen capacity should be compatible with related equipment. If the production capacity is too rich, capital investment will be wasted. Overload operation will cause wear and tear and reduce production capacity.

4. According to different screening purposes, it needs to choose different vibrating screen type, such as pre-screening material can choose circular vibrating screen; The classification and screening of materials after crushing can use large vibrating screen; Linear vibrating screen can be used to dehydrate the material.

Get Price List
  • High Quality

    Adopt punching sieve or steel sieve mesh in order to prevent blockage.Sieve beam and screen box adopts high strength bolt connection, no welding processing.

  • Customized Design

    Adopt special configuration, conform to personalized needs of the customer and meet the needs of different industries to achieve the best screening goal

  • Good Performance

    Large dip angle structure enables high screening efficiency and handling capacity

Product features

With eccentric block as exciting force, strong exciting force.

  • vibrating screen
  • double deck vibrating screen
  • vibrating screen for stone crusher
  • vibrating screen price

Working principle

YK series circular vibrating screen mainly consists of the eccentric block vibrator, screen box, motor, and supportive device. Its vibrating track is a circle and moves on a circular motion. It is a multi-layer and high efficient vibrating screen.

Motor drives the V-belt to make the eccentric block rotate in high speed, so that producing large centrifugal force to make exciter produce the amplitude in circular motion, the stone aggregates on the screen surface will be throwing motion continuously under the function of exciter, during the process of materials contacting with the screen surface, final products will be classified.

vibrating screen structure

Specification

Model Sieve specification (mm) layer Mesh size (mm) Max feeding size (mm) Processing capacity (t/h) Moto power (kw) Vibrating Frequency (r/min) Double amplitude (mm)
2YK1237 1200X3700 2 3-50 200 30-100 5.5 970 5-9
3YK1237 1200X3700 3 3-50 200 30-100 7.5 970 5-9
2YK1548 4800X1500 2 3-100 400 30-275 15 970 5-9
3YK1548 4800X1500 3 3-100 400 30-275 15 970 5-9
2YK1848 4800X1800 2 3-100 400 56-330 18.5 970 5-9
3YK1848 4800X1800 3 3-100 400 56-330 18.5 970 5-9
4YK1848 4800X1800 4 3-80 400 56-330 22 970 5-9
2YK1860 6000X1800 2 3-100 400 65-586 18.5 970 5-9
3YK1860 6000X1800 3 3-100 400 65-586 22 970 5-9
4YK1860 6000X1800 4 3-100 400 65-586 30 980 5-9
2YK2160 6000X2100 2 3-100 400 81-720 22 980 5-9
3YK2160 6000X2100 3 3-100 400 81-720 30 970 5-9
4YK2160 6000X2100 4 3-100 400 81-720 37 980 5-9
2YK2460 6000X2400 2 3-150 400 100-810 22 970 5-9
3YK2460 6000X2400 3 3-150 400 100-810 30 980 5-9
4YK2460 6000X2400 4 3-150 400 150-850 37 980 5-9
2YK2470 7000X2400 2 3-100 400 180-900 30 980 5-9
3YK2470 7000X2400 3 3-100 400 180-900 37 980 5-9
4YK2470 7000X2400 4 3-100 400 180-900 45 980 5-9
2YK2480 8000X2400 2 3-150 400 190-940 30 980 5-9
3YK2480 8000X2400 3 3-150 400 190-940 37 980 5-9
4YK2480 8000X2400 4 3-150 400 190-940 45 980 5-9
2YK3070 7000X2400 2 3-100 400 220-1000 37 980 5-9
3YK3070 7000X2400 3 3-150 400 220-1000 45 980 5-9
4YK3070 7000X2400 4 3-150 400 220-1000 55 980 5-9

*The output will vary according to different materials, feed particle size and other factors
