Magnetic Separator

Magnetic Separator

Magnetic separation is a process in which magnetically susceptible material is extracted from a mixture using a magnetic force.

  • 1450-1650oeFeed Size
  • 1.1-7.5KWMotor Power
  • 8-200 tphProcessing capacity
  • 60S Quick response
  • 30 min Technical reply
  • 24h design proposal
  • Email:hnbc@baichy.com

What is wet Magnetic Separator?

Permanent drum magnetic separator is a magnetic separation equipment for various metallurgical mines to separate magnetic fine particles or remove magnetic minerals mixed in non-magnetic minerals. Wet magnetic separator is a commonly used magnetic separation equipment in iron ore processing plants, which requires water as a medium, it can sort fine particles of ore. Magnetic separator is mainly used for magnetite, limonite, ilmenite, etc. It can separate elemental minerals from gangue, sediment to improve the quality of minerals.
iron ore processing plant magnetite ore plant

magnetic separator for iron ore.jpg

How to choose wet Magnetic Separator?

The magnetic strength of magnetic separator surface is different, and the applicable materials are also different. The stronger the magnetic field, the greater the ability to attract weak magnetic materials. The tank body of the wet magnetic separator has three forms, which are divided into semi-counter current tank, counter-current tank and downstream tank, and the semi-counter-current tank and downstream tank can be used in combination.

1. Semi-counter current tank. It is suitable for rough selection or beneficiation of strong magnetic minerals with a particle size between 0-0.5mm, especially for the beneficiation of ore particles between 0-0.15mm.

2. Countercurrent tank. It is suitable for roughing or sweeping of strong magnetic minerals with particle size between 0-0.6mm. It is especially suitable for heavy medium recovery in coal washing plants, etc.

3.Downstream tank. It is suitable for roughing or refining minerals with a particle size between 0-6mm.

4.Both the semi-counter current tank and the downstream tank can be used in series to improve the concentrate grade.

Get Price List
  • High Quality

    Short magnetic circuit and little magnetic flux leakage.

  • Customized Design

    Fine beneficiating results and simple structure and easy to maintain.

  • Good Performance

    High magnetic intensity and low energy consumption.

Product features

Short magnetic circuit and little magnetic flux leakage.

  • magnetic drum separator
  • wet magnetic separating machine
  • magnetic separation equipment
  • high gradient magnetic separator

Working principle

Slurry enters chute through ore tank, and then gets into separating zone by waterpower. Minerals with strong magnetism is absorbed on the barrel’s surface under the force of magnetic field and get into the ore concentrate outlet along with the rotation of cylinder. After leaving the magnetic field, they flow into ore concentrate box by the action of gravity and flushing water. Gangue and ore with weak magnetism are discharged into a pipe in the opposite direction of cylinder rotation.

magnetic separating plant

Specification

Model Magnetic field intensity (oe) Capacity (t/h) Power (kw)
CTB600X900 1450 8-15 1.1
CTB600X1800 1500 15-25 2.2
CTB750X1800 1550 30-45 3
CTB900X1800 1650 35-60 4
CTB1050X2400 1650 60-95 5.5
CTB1200X3000 1650 80-150 7.5
CTB1500X3000 1650 120-200 11

*The output will vary according to different materials, feed particle size and other factors
