Granite aggregates production plant in Kyrgyzstan

Granite aggregates is the most basic material used in construction in in Kyrgyzstan. It includes gravel, crushed stone, and sand. When granite aggregates are used with a binding medium, like water, cement, and asphalt, they are used to form compound materials, such as asphalt concrete and Portland cement concrete. They provide the foundation for roads, bridges, and buildings. Client from Kyrgyzstan plans to crush granite into 0-5-12-19-25mm as aggregates for local market. The max feeding size it 400mm. We suggest a three stage crushing plant with capacity 100-150 tph.

Configuration of granite crushing plant

The finished product size needs to be produced by three-stage crushing. The customer has certain requirements for the sand mold in the finished product and has high requirements for the cleanliness of the finished product. A sand washing machine is required. So we design a three stage crushing plant to meet requirement.

1.Vibrating feeder ZSW9638. It is selected according to the feeding particle size and output matching requirements.

2.Jaw crusher PE600X900. According to granite size and jaw crusher feeder opening and capacity, this model is selected.

3.Cone crusher CS160. According to the discharge curve of Symons cone crusher and the required output, the type of medium-crushing compound cone crusher is selected.

4.Vibrating screen 2YK1860. According to the crushing particle size curve of the cone, the proportion of the corresponding finished product is calculated, and then the required screening area is determined according to the respective output of the finished product, and thus the appropriate vibrating screen is selected for the pre-screening of sand products.

5.VSI sand-making machine VSI9532. Because some of the screened materials are larger than the finished product particle size, it is necessary to use an impact sand-making machine to further make sand to improve the sand forming rate.

6.Sand washing machine LS1275. Because this solution has high requirements for the cleanliness of the sand and gravel, it is necessary to configure a sand washing machine to further process the quartz sand.

Baichy Machinery provides different types and models of the above mentioned crushing equipment for granite crushing plant. And our engineers will recommend suitable type and model for you according to the specific requirements. Chat with us if you want to know price list for granite stone crushing machine.

People Also Frequenty Asked For - FAQ

1. What is aggregate processing plant?

Aggregate processing plant means a combination of fixed or portable equipment for the processing of aggregate3 including each crusher, grinding mill, screening operation, bucket elevator, belt conveyor, bagging operation, storage bin, and truck or railcar loading station, power sources such as generators, power units

2.What is aggregate in manufacturing?

Aggregates are particles of random shape. They can be either in nature as sand, gravel, stones, or rock that can be crushed into particles or obtained from by-products or waste materials from an industrial process. Aggregate sizes vary from several cm to several mm.

3.How are aggregates produced?

Aggregate materials are obtained from natural mines of sand or sand and gravel, quarries, deposits, and underground sediments. Examples of aggregate materials include: Crushed rock - These products are obtained by extracting rocks and crushing them to the desired size and texture.
